WELCOME LIGHTNING PROTECTION USING LFA-M Submitted By:Somi.P. Chacko Class: S7-EEE Roll no: MCET CONTENTS. Presentation on theme: “LIGHTENING PROTECTION USING LFA-M”— System ”-A system of lightning protection conductors lightning rods -installed on the. effective and inexpensive method for lightning protection of medium voltage overhead distribution line is using long flashover arresters (LFA).
