CATIA PRISMATIC MACHINING PDF

CATIA PRISMATIC MACHINING PDF

Learn how to machine a part by 2 ½ axis ways with Prismatic Machining workbench through an exercise. CATIA Version 5 Prismatic Machining. Upon completion of this course, you should have a full understanding of the following topics. -. Build stock material for a. CATIA – Prismatic Machining Preparation Assistant (MPA) delivers functions to prepare a design part for prismatic machining through geometrical machining.

Author: Tek Shakanris
Country: Mongolia
Language: English (Spanish)
Genre: Spiritual
Published (Last): 14 December 2011
Pages: 367
PDF File Size: 19.85 Mb
ePub File Size: 3.2 Mb
ISBN: 332-8-23269-655-4
Downloads: 64438
Price: Free* [*Free Regsitration Required]
Uploader: Kashicage

In the Pocketing dialog box, select the Prismatic machining area.

CATIA – Prismatic Machining Preparation Assistant

Locally creates a prismatic geometrical machining feature of a design part for milling and drilling machining. Click the red Bottom in the sensitive icon then select the pocket bottom in the 3D window. Locally creates a prismatic geometrical machining feature of a design part for milling and drilling machining: Select Analyze to analyze the result of the simulation.

In the Profile Contouring dialog box, select the Prismatic machining area. Click OK to create the Profile Contouring operation. Axial machining features are displayed in a TO DO LIST with a summary of their dimensioning characteristics, for a better readability, and their positions are displayed in parallel in 3D view.

Integrates geometrical machining features into the Prismatic Machining product. All generated geometrical machining features are fully integrated in the Prismatic Machining product.

Prismatic Machining

Select Manufacturing View to display the Manufacturing View. All CATIA standard holes and milling features, such as pockets, steps and cutouts, can be individually created. Geometrical machining features integration in prismatic machining product: The tool entry direction for a Prismatic machining area is the normal to the selected bottom.

  ANNUARIO TATUATORI ITALIANI 2014 PDF

The pocket boundary Guide. All recognized geometrical machining features are presented in the manufacturing view of the design part to be machined by the CATIA Prismatic Machining product. Automatically build geometrical machining features for prismatic machining using, advanced feature recognition techniques.

CATIA – Prismatic Machining Preparation Assistant

By using our website you consent to all cookies in accordance with our cookie policy. Training will begin with 2-D contouring, pocketing, drilling, tapping, boring, and turning operations then advance to more machininh 3-D surface toolpath development.

You can refer to Edit the Tool of an Mqchining for more information. Verify the Profile Contouring operation by simulating the tool path in Video simulation mode.

Any modification to this geometry in mafhining operation will also modify the geometry of the feature. All geometrical machining features can be fully machined with all CATIA – Prismatic Machining PMG strategies, from elementary machining operation creation up to automatic complex machining process application in both drilling and milling domains.

Select the Macros tab to specify a Retract macro with a linear Retract path of 50mm. Therefore it builds a real manufacturing view of the design Part catiia all the drilling and milling features to be machined. Close the Analysis and Replay dialog boxes.

CATIA V5 PRISMATIC & ADVANCED MACHINING

Select Prismatic Machining Area. This feature references the macyining pocket geometry. Participants interested in this program must be able to demonstrate their skills using CATIA for part modeling and design. Use the Sort by Machining Features contextual command to see how the Prismatic machining area is referenced by the Pocketing and Profile Contouring operations. Product Highlights Automatically madhining all prismatic geometrical machining features of a design part for milling and drilling machining.

  GANAPATI ATHARVASHIRSHA TELUGU PDF

The resulting prismatic geometrical machining features are managed in the manufacturing view in the prismatic machining workbench. All CATIA standard holes and milling features such as pockets, steps and cutouts are prisamtic and can be recognized. Note that it is available only when the NC Manufacturing Verification product is installed.

Please complete our form for more information and a PDC representative will contact you. This website uses cookies to improve user experience. You can see that the remaining material has now been machined by the Profile Contouring operation.

If required, the user can easily choose feature types to be recognized. These features can be used in either individual prismatic machining strategies or complex machining processes, further smoothing design to manufacturing integration.

Select the Macros tab to specify an Approach macro with a linear Approach path of 50mm. Note that to enable this simulation you must reference the design part in the Part Operation editor.
